Laser Cutting Services



gold micro laser cutting

.010" triangular holes in .015" thick PZT wafer, pattern of electrodes (selective machining on gold), minimum feature .002", magnification 70x

At Gateway Laser, we specialize in providing precision laser cutting services with an emphasis on very small parts that require exceptional edge quality and extremely close tolerances.

The need for more precise features, better edge quality, smaller heat-affected zones and lower cost led to our development of the High Resolution Laser Microcutting process.

With this process, we can produce features below .002” in size for a variety of applications, including:

  • Slots for masks
  • Hole orifices for gas flow restrictors
  • Slits in optical apertures
  • Patterns with good edges and sharp radii
  • Tubular parts with specific patterns.

Nitinol pattern laser cut   Stainless steel reticle .003" thick, pattern .002" geometry; magnification 70x.


.0016" wide spring, brass .001" thick; magnification 70x.   150 Micron serpentine worm pattern in brass, .002" thick.
